ZF100-6

ZF100-6

1) Factory design with competitive price.
2) Best policy: Quality, Honesty and Innovation.
3) Detailed package and transportation with good after-sale service
4) MOQ :20GP container
5) Port: Chongqing, Guangzhou, Shanghai
6) Payment Terms: T/T,L/C,D/P

Categories

Engine Type: Single cylinder, 4 stroke, air-cooled
Bore×Stroke(mm) 50×49.5
Piston Displacement(ml)97
Compression Ratio9.1:1
Maximum Power(kw/rpm)4.8/8000
Maximum Torque(N.m/rpm)6.5/5000
Ignition TypeCDI
Starter System:Electric/Kick
L×W×H(mm) 1830×650×1090
Wheel base(mm)1210
Ground Clearance(mm)150
Dry weight(kg)92
Brake(front/rear)Drum/Drum
Front Tyre Size2.50-17
Rear Tyre Size2.75-17
Fuel tank capacity(L)4
